  (1) Pulse conditions of 1/10 duty cycle @ 0.1ms width
Reverse Voltage

5 Volt

Operating Temp. Range -30 - +85 deg C
Storage Temp. Range -30 - +85 deg C
Lead Solder Temperature 260 deg C -for 4 seconds
Parameter Description Symbol Unit Value
Power dissipation Pd mW 100
Recommended Forward Voltage Vf (Rec) V 3.3
Peak Forward Voltage Vf (Peak) V 3.8
Recommended Operating Current If (Rec) mA 20
Peak Pulse Current (1) If (Peak) mA 100
Average Luminous Intensity Iv mcd 250
