Lighting Accessories



























Desc. Item# Cart Price
   5 ft. #29 Wire  N5029
$4.50
   5 ft. #32 Wire  N5032
$4.00
More Info
Specifications
Designed specifically for applications that require repeated flexing such as voice coils, linear actuators, and robotics, this wire is extremely supple due to it's high quantity of small strands and super "limp" insulation. At 0.032" nominal overall diameter, the #29 wire is only 0.001" larger than typical decoder wire, but instead of the normal 9 strands, it contains 51 strands of #46 (0.0015") copper wire. It will carry 600ma of current so it is ideally suited for most motor power wiring in Z-Scale, N-Scale and HO. If more power is needed in larger scales, just run additional wires in parallel. Perfect for steam locomotives which usually place decoders in the tender (no more derails). The #32 wire is extremely small for insulated wire with an overall nominal diameter of 0.023". It contains 18 strands of #44 copper wire and will carry 250ma of current. This wire is ideally suited for lighting applications that require flexing of the power connections (truck pickups on rolling stock, crossing gates, bridge lifts, etc. It is also well suited for some lower-current Z-Scale motors. The possibilities are endless.



Super-flexible Wire









#30 Insulated Hookup Wire
Item# Cart Price
N5030W
$3.95
N5030B
$3.95
N5030R
$3.95
More Info
Specifications



Our hookup wire is packaged in 50-foot lengths on handy notched spools to prevent unraveling on your workbench. This silver-plated solid copper wire takes solder very quickly and will easily carry 300ma of current. It is available in white, black and red and is excellent for wiring LED lighting, small motors, switches and many hobby projects. It is very handy as a durable intermediate connection between our Power Distribution Board (below) and our fine #38 magnet wire (above) where a run of a foot or more is required.







    #38 Magnet Wire
This magnet wire is ideally suited for devices that draw less than 35ma current. Manufactured by Superior Essex, Inc., this wire's small size (about .0045" diameter including insulation) allows it to be easily hidden or used as "prototypical electrical cable in actual wiring situations (see photos). The Soderon® insulation is quite durable and can be painted for further concealment or required effects. It is easily stripped as part of the wire tinning process. For easy use, we package it on a 2-layer bobbin.

Get Acrobat Reader



More Info
Specifications
Compare size
Photos
Using the wire
Desc. Item# Cart Price
 100 ft. red/green  N5038
$4.95
   Tiny Bridge Rectifier
Manufactured by Fairchild Semiconductor® as their MB1S, this little bridge rectifier is the perfect solution for lighting or other DC devices in N-scale rolling stock running on a DCC layout. Using a very simple circuit (see wiring tips), it will turn a pulsed DCC signal into DC to drive any device you might want to use, up to a full 1/2 AMP! It can handle up to 1.4Watts (1400mW) of power. Suppose you wanted to power our 3.6-volt 2x3 Super LEDs (our highest device voltage LEDs)... no problem! Using a 12-volt source, and series/parallel wiring, this little bridge could handle 18 of them! If need be, the contact legs can be folded under the device to further reduce its footprint .

*Data sheets are in Adobe Acrobat format Adobe PDF icon

More Info
 Data Sheet *
Compare size
Photos
Wiring tips
Packaging
Desc. Item# Cart Price
  2-pack    N301S-2
$1.85
 10-pack    N301S-10
$8.40
RECTIFIES A FULL 1/2 AMP
SOLDER STRIPPABLE
         INSULATION



 50-volt 0.1μf ceramic

  SMD Capacitor

 3/64" diameter Shrink Tubing

 Resistor/LED Mounting Board

 20ma Current Source

  for LEDs

  Snap-on 9-volt

   Battery Clip

  12 & 18-volt Regulated  Switching Power Supplies

  1/10 watt, 1/8 watt , 1/4 watt & 1/2 watt SMD Resistors

More Info
 Data Sheet *
Compare size
Wiring tips
Packaging
Desc. Item# Cart Price
 2-pack N302S-2
$3.95
 10-pack N302S-10
$18.95
More Info
Specifications
Compare size
Usage tables
Calculators
Packaging
Desc. Qty. Item# Cart Price
1/4-watt (1206 case size) Resistors
 100 Ω ¼ w 20 NB1000
$1.65
 301 Ω ¼ w 20 NB3010
$1.65
 340 Ω ¼ w 20 NB3400
$1.65
 357 Ω ¼ w 20 NB3570
$1.65
 402 Ω ¼ w 20 NB4020
$1.65
 453 Ω ¼ w 20 NB4530
$1.65
 523 Ω ¼ w 20 NB5230
$1.65
  1K Ω ¼ w 20 NB1001
$1.65
  3K Ω ¼ w 20 NB3011
$1.65
 5.1KΩ ¼ w 20 NB5111
$1.65
1/2-watt (1210 case size) Resistors
 510 Ω ½ w 20 NC5100
$2.65
 560 Ω ½ w 20 NC5600
$2.65
 620 Ω ½ w 20 NC6200
$2.65
 750 Ω ½ w 20 NC7500
$2.65
 820 Ω ½ w 20 NC8200
$2.65
  1K Ω ½ w 20 NC1001
$2.65
  1.5K Ω ½ w 20 NC1501
$2.65
 Assortment Packs
   Assort. 9V 150 NX9V
$9.85
  Assort. 12V 170 NX12V
$11.50
  Assort. 18V 230 NX18V
$15.95
Desc. Qty. Item# Cart Price
1/10-watt (0603 case size) Resistors
  1K Ω 1/10w 20 NAA1001
$1.65
  3K Ω 1/10w 20 NAA3001
$1.65
1/8-watt (0805 case size) Resistors
   61 Ω ⅛ w 20 NA60R4
$1.65
   81 Ω ⅛ w 20 NA80R6
$1.65
 100 Ω ⅛ w 20 NA1000
$1.65
 121 Ω ⅛ w 20 NA1210
$1.65
 150 Ω ⅛ w 20 NA1500
$1.65
 178 Ω ⅛ w 20 NA1780
$1.65
 200 Ω ⅛ w 20 NA2000
$1.65
 232 Ω ⅛ w 20 NA2320
$1.65
 274 Ω ⅛ w 20 NA2740
$1.65
 301 Ω ⅛ w 20 NA3010
$1.65
 510 Ω ⅛ w 20 NA5100
$1.65
   1K Ω ⅛ w 20 NA1001
$1.65
 1.5KΩ ⅛ w 20 NA1501
$1.65
   2K Ω ⅛ w 20 NA2001
$1.65
  3K Ω ⅛ w 20 NA3011
$1.65
 5.1KΩ ⅛ w 20 NA5111
$1.65
  10KΩ ⅛ w 20 NA1002
$1.65
13.3KΩ ⅛ w 20 NA1332
$1.65
15.4⅛ w 20 NA1542
$1.65
  21K Ω ⅛ w 20 NA2102
$1.65

Manufactured by Vishay Electronics and KOA Speer, two of the worlds largest makers of thick-film surface-mount (SMD) components, these tiny resistors provide the same power capabilities as their much larger axial-lead cousins. We've greatly expanded our selection to include a wide variety of resistance values in 1/10, 1/8, 1/4 and 1/2 watt sizes. The selection includes values specifically suited for current protection of our LEDs operating in either 9-volt, 12-volt, or 18-volt  applications common to N, Z,  HO & O-Scale DC and DCC, as well as values to allow the "tuning" of LED intensities for specific uses and projects. The Usage tables link above provides a comprehensive selection guide and the Calculators link makes custom tuning of LEDs quick and easy.

These resistors easily fit in the smallest spaces due to their flat, rectangular shape and miniature size. The solder pads on each end are pre-tinned for easy connection.

We also offer three different resistor assortment packs. A 9-volt pack, a 12-volt pack, and a 18-volt pack. A detailed listing of their contents can be found by clicking on either the Assortment Pack Item# or Desc. below

SMALLEST BRIDGE RECTIFIER

MADE... ANYWHERE!







     Miniature 16-volt & 25-volt Capacitors

More Info
Data sheet 16V
Data sheet 25V
Compare size
Photos
Wiring tips
Packaging
Desc. Item# Cart Price
  16-volt 100uf 6-pack N3100-6
$4.95
 16-volt 100uf 24-pack N3100-24
$17.80
16-volt 220uf 5-pack N3220-5
$7.95
16-volt 220uf 15-pack N3220-15
$18.95
 25-volt 68uf 10-pack N3068-10
$11.10
 25-volt 68uf 40-pack N3068-40
$39.95
Whether you're installing interior lighting in passenger cars, marker lights on cabooses, flashing rear-of-train devices, or cab lights in locomotives, nothing can be more irritating than watching the flickering that occurs when your rolling stock's wheels travel over dirt or gaps in the rail. Adding 500μf to 1000μf capacitance to your lighting circuit minimizes, and often virtually eliminates this problem.



Compared to typical film-wound capacitors these tantalum capacitors have a much smaller case size for the same storage capability. The N3100 is 100μf (microfarads) at 16-volts and is supplied in either a 6-pack or 24-pack. The N3220 is 220μf (microfarads) at 16-volts and is supplied in either a 5-pack or 15-pack.The N3068 is 68μf (microfarads) at 25-volts and is supplied in either a 10-pack or 40-pack.These capacitors can be "ganged" in parallel to achieve the amount of capacitance you need while still fitting in very small spaces. The 25-volt capacitors are ideally suited for HO power packs that exceed 16-volts DC, and most S, O and G scale power supplies.

 DCC Trak-Pak

 Miniature Switches

 Ultra-miniature

SPDT Switch

Desc. Item# Cart Price
  2-pack   N3200-2
$2.85
 10-pack   N3200-10
$13.25
More Info
Data sheet *
Compare size
Photos
Packaging
The N3210 toggle switches are a perfect choice for many different electrical wiring/switching applications, and come in a handy 5-pack with all of the mounting hardware. Center contact is the common wiper so they can be wired for on/on routing applications, as well as on/off.

The N3211 momentary push-button switches have hundreds of applications and also come in a 5-pack
The DCC Trak-Pak combines several of our products to provide easy adaptation of our lighting or sound effects to rolling stock for Z, N and some HO scales. A complete list of what's included can be found by clicking on the Contents link in the More Info table above. We have used this product in an N scale cattle car to demonstrate our Little Bigger Sounds effect for cows, using our sound board, amplifier board and speaker, all located inside the car, running on track power. The effect is quite dynamic. To see the details of this installation, click on the Example of use link in More Info above. The Using link above completely covers adaptation and installation. The N8131B version can support up to a 25-volt input for larger scales such as all HO, S & DC O Scales. (remember the 350mW power rating).
If you need an incredibly small SPDT switch to turn something on and off, or switch between two devices, we've got just the one for you. Made by ITTCannon, this little slide switch features silver contacts and will carry 150ma at 12 volts! To see just how small this little fellow is, click on the Compare size link above. Incredible! Mechanically rated at 10,000 cycles, it will certainly last. The sliding action has a positive "click".
Micro Bridge Rectifier



And... (drum roll please) for those of you who need a really small bridge rectifier, here's the industry's smallest! This little guy is the proud product of Central™ Semiconductor Corp. It will rectify 140ma of current and handle up to 50-volts DC on a continuous basis. It can dissipate 350mW of power, so with a 12-volt source, proper resistor for current control and series wiring, it could easily power 4 of our 3.3-volt 2x3 Super LEDs, and could power many more of our red and/or yellow LEDs.

Z-Scale enthusiasts: Space limitations for rectifying analog or DCC track voltage for lighting of any rolling stock is now history. This bridge rectifier will fit anywhere!















ANALOG AND DCC READY

























Desc. Item# Cart Price
Single-pack N8101
$3.95
5-pack N8101-5
$17.78
Single-pack N8101B
$4.45
5-pack N8101B-5
$19.95
More Info
Connecting
Analog support
DCC support
AC support
Evolution



DC Power Source







And.., and... (before the drum roll stops) for those of you who need a reeeeeally small bridge rectifier using schottky diodes for the lowest possible voltage loss (important for analog operators), combined with the industry's smallest 10μf multi-layer filter capacitor (important for DCC operation), all mounted on a tiny (0.320" x 0.150" x 0.085") circuit board with handy solder points. But wait... there's more.., it also has an additional solder point for direct connection of an LED plus solder pads on the back of the board for the LED's current protection/brightness control resistor. This module can rectify and filter up to 140ma continuous duty and can handle 350mW of power. With 12-volts as a source, it can support passenger car lighting or one of our Simulator modules and its LEDs. It can handle a maximum of 16-volts, so it will support HO as well as N and Z scales. The N8101B can handle a maximum of 25-volts DC.





















LED Power Distribution Jr.
LED Power Distribution Board



Item# Cart Price
N8105

$5.95

Item# Cart Price
N8102

$11.95

More Info
Board layout
Choosing power
Tuning LED brightness
Wiring examples
Expanded LED wiring
Adding switches
Simulators & Flashers
More Info
Board layout
Choosing power
Tuning LED brightness
Expanded LED wiring
Adding switches
Simulators & Flashers







The N8102 is designed to provide a convenient way to connect power to multiple LEDs from a single power source. It is ideal for lighting projects such as in model railroad structures, street lighting, dioramas, or anywhere that multiple LED light sources are needed. At only 1.40" wide x 3.40" long, the N8102 is packed with capability.  Side A (front) of the board provides power for up to 16 LEDs by using highly-regulated 20ma current sources. These sources will support 20ma LEDs of any color and colors can be mixed within a group. Solder pads are provided for optional brightness-adjustment resistors to allow individual control of intensity of every LED if desired. Side-B (rear) of the board provides connection for up to 12 additional LEDs. These connections have solder pads for LED current control resistor placement. This module will support a power supply input voltage of up to 18 volts-DC. Nylon spacers for mounting are included with each board.

Just like its big brother above, this LED Distribution Board has a 20ma current source on the board top surface to provide highly-regulated current for up to 4 LEDs. This source will support 20ma LEDs of any color and colors can be mixed within the group. Solder pads are provided for optional brightness-adjustment resistors to allow individual control of intensity of every LED if desired. The bottom side of the board provides connection for up to 4 additional LEDs, which can be connected as one or more series groups, individually (parallel) wired LEDs, or a combination of both. These connections have solder pads for LED current control resistor placement. This module will support a power supply input voltage of up to 18 volts-DC. A nylon spacer for mounting is included with each board.















































Constant Voltage Circuits  for N & Z scales
AC/DC to DC Adjustable Voltage Converter
Constant Voltage Circuit  for HO, S, O & G scales





Configured for connecting up to three white, yellow-white, warm-white or incandescent (3.3-3.6 volt) LEDs. Works well for most passenger cars, MOW cars and cabeese (cabooses).











These tiny little circuits are the same small size as our Lighting Effects Simulator boards (.310" x .310") and a bit thinner at .100". They use a very tiny high-precision pass-through 3.3-volt regulator to maintain a  constant output voltage and can handle DC input (track) voltages of up to 16-volts. This makes them perfectly suited for N and Z scales. The NL8014 is designed as a uni-directional circuit for up to 2 LEDs with device voltages of 3.3 (standard "white varieties"). It contains a schottky barrier diode that prevents the circuit from functioning when track polarity is reversed which make this version ideal for locomotive headlights operating in an analog (non-DCC) environment. The NL8104-2 is a 2-pack of the modules.

The NL8104B is configured for bi-directional operation and up to 3 LEDs ("white varieties"). This makes the circuit ideal for passenger car lighting in an analog environment. The NL8104B-2 is a 2-pack.

Both circuits have connection points for external capacitor hookup for flicker control.

This little board supports an extremely wide range of input voltage (up to 25-volts!) while maintaining constant output  for up to 3 LEDs. Unlike other circuits, ours uses a "pass-through" regulator, not a buck or buck-boost type which keeps output off until regulation threshold is achieved. That means that whatever the low-end track voltage is, it gets passed through to the output. In short... the lights will start turning on at lower voltages. Input is schottky bridge rectified to ensure the lowest voltage loss and circuit power regardless of track polarity. Our N8104 boards are ideal for HO, S, O and even G-scale using DC or DCC.  Flicker control is maintained by a powerful 680uf 25-volt electrolytic capacitor with the smallest case size available in industry today. If track voltages are AC, the upper voltage limit is 14.5 AC volts. This is because the RMS value (peak rectified voltage) will actually be 20+ volts DC in the circuit.

The N8104-2 is the same circuit with the flicker control capacitor included in the package but uninstalled on the board. This provides more flexibility for limited space applications where remote location of the capacitor would be beneficial.

The N8014-3 is the circuit without the flicker control capacitor. This would be either for applications where customers have their own capacitors or, for lighting stationary structures.











































More Info
Data Sheet *
More Info
Using
Do's and Don't's
Applications
More Info
Applications









These miniature capacitors are manufactured by Kemet and use a tin over nickel barrier for easy end solderability. Rated at 50-volts, these 0.1 microfarad ceramic capacitors will support a wide range of circuit voltages and are very useful for suppression of high-frequency or transient voltage spikes in electronic circuits. Their .125" X .063" case size makes them easy to handle yet small enough to be located in the most confining situations. Click on the Applications link under More Info above for more information on use related to model railroading.



Desc. Item# Cart Price
2-pack N90CL2-2

$3.25

10-pack N90CL2-10

$14.95

Desc. Item# Cart Price
20-pack N8106-20

$4.95

Desc. Item# Cart Price
5-pack N5364-5

$3.25

Desc. Item# Cart Price
10-pack N950V.1-10

$1.25

 © 2020 Ngineering



In addition to be an excellent stationary voltage converter, this module is especially useful for larger scale rolling stock as it can handle both AC and DC input voltages. The output voltage is adjustable and will maintain accuracy to within +/- 0.5%. Depending on the output voltage setting it can support up to 2 Amps of current output. Please see specification details by clicking on the Specifications link in the More Info table above.

You asked and we responded! These highly versatile miniature circuit boards can be used for mounting resistors, LEDs, and other components and have thru-hole solder points for easy wiring. They are backed w/double-sided Kapton® tape which can withstand 500° F. Each strip of 10 boards is pre-grooved between the boards for easy separation (after tape is cut). Now, placing an LED with its appropriate resistor couldn't be easier - solder it up and stick it in place! These boards will support SMD resistors up to 1/2-watt in size and LED sizes up to our 2x3mm ones.

Our 5-pack of 3/64" diameter shrink tubing is back in stock. The package contains 5, 4-inch lengths of green polyolefin shrink tubing. Ideal for insulating those tiny decoder wires or any small wire that requires solder joint protection. 2:1 shrinkage. Shrink temperature 120 deg C (248 deg F) Operating temperature -55 to 135 deg C (-67 to 275 deg F). Can be painted with any acrylic paint after shrinking

This tiny device manufactured by Supertex is a high voltage, temperature compensated, constant current source. It provides a constant current of 20mA±10% over an input voltage range of 5-90 Volts DC, and can be used as a constant current source or a constant current sink. Multiple devices can be connected in parallel to provide higher current such as 40mA, 60mA, 80mA, etc.





More Info
Contents
Example
Using
More Info
Specifications
More Info
Specifications
Item# Cart Price
N8131

$10.45

N8131B
$12.25
Item# Cart Price
N2596

$8.95

Item# Cart Price
N3210-5

$6.95

N3211-5
$4.95
Item# Cart Price
N3301-4

$7.95

Item# Cart Price
NL8104

$9.95

NL8104-2
$17.95
NL8104B

$11.95

NL8104B-2
$21.95
Item# Cart Price
N8104-1

$15.95

N8104-2

$15.45

N8104-3

$14.95

These handy snap-on battery clips (4 per package) will connect to any PP3 type 9-volt battery (alkaline, NiCad, or Lithium). The snap connectors are nickel-plated steel for long life and the posts are tin-plated brass for easy soldering. The posts can be easily cut shorter for circuit board mounting applications.

NEW ITEM!
NEW ITEM!
These power supplies provide highly regulated voltage output so your lighting or special effects won't get fried.. Our new N3512B replaces the earlier N3512 & N3512A versions we provided for many years. This new "B" version provides 12 volts and 1.5 Amps continuous-duty output instead of 1.25 Amps like the earlier "A" version, and is priced the same. It can handle nearly any lighting project and requires only minimal space. It can power nearly 225 white LEDs (using series/parallel wiring). The 6-foot supply cord is equipped with a EMI/RFI filter to minimize electrical interference. This is a true switching power supply like the kind inside your computer. Unlike the "wall warts" (battery eliminators) available at many electronic stores for $8-$12, it doesn't use a transformer or have a simple two-diode circuit. And, it has over-current and short-circuit protection. The N3518 supplies 18 volts and .825 Amps continuous-duty output.  It can easily power 225-250 white LEDs, and being 18-volts, it can easily power many 9-LED (red, yellow or green) series strings.
Item# Cart Price
 N3512B
$16.95
N3518

$16.95
